• 유량 100L/min
• 컬러 터치스크린
• 5,000 샘플 저장
• 6채널
• 충전식 배터리

​​

◆ 주요 특징 ◆

1) 우수한 성능의 수명이 긴 레이저사용

2) 3400시리즈 중 원하는 샘플용량별로 모델선택가능

  : 28.3 LPM (1.0 CFM) 50 LPM (1.77 CFM) or 100 LPM (3.53 CFM)

3) 사용자 친화적 인터페이스 사용

4) 국제 규격 ISO 14644-1 모든 입경 동시만족

5) Test Wizard for easier compliance

​

◆ MET ONE 3445  스펙 ◆

▶ STANDARD SIZE CHANNEL : 0.5um,1.0um,2.0um,3.0um,5.0um,10.0um(6Channel)

▶ FLOW RATE :  100.0LPM

▶ PUMP TYPE : Air Vacuum

▶ COUNT DISPLAY : Color 1/4 VGA TFT Touch Screen

▶ INTERFACE : Windows CE Based

▶ DATA STORAGE : 5,000 samples, scrollable on Historical Data review screen

▶ COMMUNICATION INTERFACE :  RS-232, RS-485, 802.11 b/g Wireless, 802.3

                                             Ethernet,USB Client (Version 1.1), USB Host (Version 1.1)

▶ BATTERY TYPE : Lithium ion smart battery; rechargeable, ejectable and hot swappable

▶ OPERATING TIME : 28.3 LPM (1.0 CFM) and 50 LPM (1.77 CFM) up to 6 hours**
                                       100 LPM (3.53 CFM) up to 3 hours**

▶ BATTERY RECHARGE TIME : 6.75 hours minimum, 10 hours maximum

▶ POWER : 24 VDC 3.2 A with 100~240 VAC 50/60 Hz adapter (included in ship kit)

▶ SIZE DIMENTIONS : 31.8 W x 25.4 D x 20.3 H cm (12.5 x 10 x 8 inches)

▶ WEIGHT(WITHOUT BATTERY) : 3413 and 3415 7.55 kg (16.6 lbs)
                                                              3423 and 3425 8.33 kg (18.3 lbs)
                                                              3445 8.65 kg (19.0 lbs)

▶ ENCLOSURE MATERIAL : Stainless Steel

▶ ENVIRONMENT : Operating: 0 to 40° C (32 to 104° F),
                                   10 to 90% relative humidity, non-condensing
                                   Storage : -40 to 50° C (-40 to 122° F),
                                   0 to 98% relative humidity, non-condensing

▶ WARRANTY : 1 years (instrument), 3 years (Long Life Laser diode)

◈  METONE 3445+  모델로 업그레이드됨.
